المواصفات
حساس حركة خارجي يعمل في اتجاهين مختلفين
الحكم الذاتي المتميز
نظرًا لاستهلاكها المنخفض للطاقة ، تعمل DualCurtain Outdoor لسنوات من البطاريات المثبتة مسبقًا. سيتم تحذير محطة المراقبة والمستخدمين مسبقًا بشأن الحاجة إلى صيانة الجهاز.
احسب وقت تشغيل الجهاز في منشأتك
لا يمكن أن يُصاب DualCurtain Outdoor بالعمى أو التعطيل بشكل غير ملحوظ حتى لو تم نزع سلاح Ajax. يتم تعزيز الأنظمة البصرية للكاشف بأجهزة استشعار متطورة للإخفاء تستجيب للعقبات وتغطي العدسات وتلوينها. لن يسمح العبث بإزالة الجهاز بشكل غير ملحوظ من الحامل. وحتى إذا تم تدمير الكاشف على الفور ، فسوف يستغرق الأمر أقل من دقيقة لاكتشاف فقدان الاتصال وإبلاغ محطة المراقبة المركزية والمستخدمين بالمشكلة
يتم ضبط نطاق الكشف للنظامين البصريين بشكل مستقل. يتيح لك ضبط المحيط الذي يحرسه DualCurtain Outdoor بدقة وتجنب الإنذارات الكاذبة التي تسببها الأدغال المتمايلة في مهب الريح أو الأشخاص الذين يمرون على رصيف عام. حتى لا يتم حظر مجال رؤية الكاشف بواسطة عمود أو ماسورة سفلية على واجهة ، يمكن نقل الأنظمة الضوئية رأسياً. في التطبيق ، يمكنك ضبط الحساسية أو إلغاء تنشيط أحد الأنظمة البصرية.
DualCurtain Outdoor can not be unnoticeably blinded or disabled even if Ajax is disarmed. Detector’s optical systems are reinforced with advanced masking sensors that respond to obstacles, covering and painting the lenses. The tamper will not allow to unnoticeably remove the device from the mount. And even if the detector is instantly destroyed, it will take the hub less than a minute to detect the loss of communication and inform a central monitoring station and users about the problem.
How the ELSA digital algorithm works
Know-how
Efficiency in the near area
DualCurtain Outdoor features a technology to expand the protected area, which is unique among outdoor curtain motion detectors. When Near Area Detection is enabled, the detector’s upper PIR sensor receives an additional narrow viewing sector directed at the angle of 40 degrees down against the main sector. The feature allows both sensors to detect movement when a human crosses the protected perimeter closely to the detector’s body, addressing the problem of the blind spot, which is a typical problem of such detectors.
Near Area Detection is designed to protect windows and other passages that animals have no access to. The proximity of the detection zones’ vectors significantly reduces the efficiency of pet immunity.
Near Area Detection mode is a patented technology of Ajax Systems.
Near Area Detection technology is supported by both DualCurtain Outdoor optical systems
Near Area Detection
Settings
One enclosure. Two independent detectors.
The detection range of the two optical systems is adjusted independently. It allows you to precisely set the perimeter guarded by DualCurtain Outdoor and avoid false alarms caused by a bush swaying in the wind or people passing on a public sidewalk. So that the detector’s field of view is not blocked by a column or downpipe on a facade, the optical systems can be shifted vertically. In the app, you can adjust the sensitivity or deactivate one of the optical systems.
The range is determined within 15 meters for each optical system
Detection distance
Sector of view of each optical system shifts 3° horizon
Frequent pings by a hub
Outstanding autonomy
Due to its low energy consumption, DualCurtain Outdoor operates for years from pre-installed batteries. A monitoring station and users will be warned in advance about the need for the device maintenance.
Calculate device’s operation time at your facility
Installation without brain teasers
The process of connecting and configuring DualCurtain Outdoor saves the installation engineer’s time in the best possible way. To add a detector to the system, all you have to do is scan the QR code with the Ajax app, assign a name and a room to it. Configure the device in the app in real time while testing detection zones and communication. If necessary, the detector can be disabled or its system parameters can be reconfigured remotely, without site visits.
